Digital Pressure Gauge, Multi-Output Signal
Model: TWM30
- Support multiple working modes
- Buit-in buzzer with sound-light alarm, field programmable alarm pressure value
- Used to measure fan and blower pressure, filter resistance, medical equipment, etc
- Responsive after-sales service / Customizable /
- High quality / One-year warranty
- The image is for reference; the actual product willbe based on your custom specifications.
Description
The TWM30 is a multi-output, multi-mode digital differential pressure gauge designed for versatile HVAC and automation applications. It supports 4–20mA, 0–10V, and RS485 outputs, along with dual SPDT relays for pressure control, alarms, and duct monitoring. Available in ±100 Pa, ±1000 Pa, and ±10000 Pa ranges, it offers multiple pressure units and features a backlit LCD, adjustable filtering, peak/valley display, programmable setpoints, and delay timers. With IP54 protection and multi-directional air inlets, the TWM30 is ideal for fan/blower monitoring, filter resistance detection, medical devices, and building automation systems.
Specifications
| Electrical connections | Cable outlet (0.5 cm) |
|---|---|
| Nominal size | 4.5" |
| Pressure medium | Gas |
| Scale ranges | 0 type: -1000 ... 1000 Pa 2 type: -10000 ... 10000 Pa 6 type: -100 ... 100 Pa |
| Pressure units | Pa, kPa, mbar, mmHG, inWC, mmWC |
| Accuracy | ±1.0% F.S. |
| Process connection | Quick coupler Air inner way: front panel, back panel, side panel |
| Case/Ring | ABS |
| Pressure limitation | 0 type: 10 kPa 2 type: 80 kPa 6 type: 5 kPa |
| Ambient temperature | -20℃ ... 60℃ |
| Medium temperature | -10℃ ... 60℃ |
| Display | LCD, switchable backlight button |
| Voltage supply | DC 16-30V |
| Output signal | None, 4-20mA & 0-10V, RS485 |
| Relay | 2 SPDT RELAYS 3A@250VAC/30VDC |
| Control signal | None, 2 SPDT RELAYS |
| Power consumption | ≦ 2.5W |
| Protection level | IP 54 |
| Weight | 360 g |
